| Camera |
| General | - Sensor: 1/4" color CMOS sensor
- Resolution: 640 x 480 pixels
- Board Lens
- Focal Length: 4.6 mm
- Aperture (F/No): F2.6
- Minimum illumination: 0 lux
- Diagonal Viewing angle: 60 degrees
|
| Audio | - Built-in omni-directional microphone
- Sensitivity: -48dB +/- 3dB (5 meters max.)
- Frequency:50~16000Hz
- Codec: PCM
|
| Hardware |
| Network | IEEE 802.3u 10/100Mbps Fast Ethernet, Auto-MDIX |
| LED | Power, Link |
| Reset Button | Restore to factory default |
| Power Consumption | 6 Watts max. |
| Power | 6 Watts max. |
| Power | 5VDC, 2.5A external power adapter |
| Dimension | 70 x 100 x 57mm (2.7 x 3.9 x 3.0 in.) |
| Weight | - Camera: 155g (5.5 oz.)
- Stand: 135g (4.8 oz.)
|
| Temperature | - Operating: 0°C ~ 45°C (32°F ~ 113°F)
- Storage: -15°C ~ 60°C (5°F ~ 140°F)
|
| Humidity | Max. 85% (non-condensing) |
| Certifications | CE, FCC |
| Requirement |
| Management Interface | Internet Explorer 6.0 or above |
| To Run Software | Windows 7(32/64-bit), Vista(32/64-bit), XP(32/64-bit) |
| SecurView Pro | - Channel: supports up to 32 cameras
- Record/Playback/Motion Detection
|
| Network Protocols | TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, PPPoE and UPnP |
| Wireless |
| Standard | Based on IEEE 802.11n technology
IEEE 802.11g/b compliant |
| Frequency | 2.4 ~ 2.4835GHz |
| Antenna | 1 x 2dBi dipole antenna (Reverse-SMA connector) |
| Data Rate (auto fallback) | - 802.11n: up to 150Mbps
- 802.11g: up to 54Mbps
- 802.11b: up to 11Mbps
|
| Security | 64/128-bit WEP, WPA/WPA2-PSK |
| Output Power | - 802.11n: 15 + 1 dBm
- 802.11g: 15 + 1 dBm
- 802.11b: 18 + 1 dBm
|
| Receiving Sensitivity | - 802.11n HT20: -67dBm
- 802.11n HT40: -64dBm
- 802.11b: -70dBm
- 802.11g: -87dBm
|
| Channel | 1~11 (FCC), 1~13 (ETSI) |
| Management |
| Remote | Remote management supported |
| Backup / Restore | Save/retrieve configuration files |
| Settings |
| Image | Brightness, contrast, saturation and mirror (horizontal/vertical) |
| Video | - Encoding type: MJPEG
- Resolution: 640 x 480, 320 x 240, 160 x 120
- Frame rate: 1~ 30 fps
- Compression: 5 levels
|
| Recording | Recording type: continuous, schedule or motion detection with software |
| Port Settings | HTTP port: 80 (default) |
| Digital Zoom | 3x |
| Dynamic DNS | Yes |
| Time | Synchronize with NTP server or set time/date manually |
| SMTP | SMTP mail supported up to 2 accounts |
| System log | 100 items |
